高压喷淋清洗机在所有的清洗方式中,其设备的效率较好,效果统一的一种方式,之所以喷淋清洗机能够达到如此的效果,是与它独特的工作原理和清洗方法密切相关的。我们知道,在生产和生活当中,需要清洁的东西很多,需要清洗的种类和环节也很多,如:物件的清除油污、灰尘、表面防锈等,常见的手工清洗方法速度慢、成本高。而喷淋清洗机则可以对工件批量清洗,效果统一、可控性强,低成本,因此,喷淋清洗机被日益广泛应用于各行各业。
High pressure spray cleaning machine in all cleaning methods, its equipment efficiency is better, the effect of a unified way, the reason why the spray cleaning machine can achieve such an effect, is closely related to its unique working principle and cleaning method. We know that in production and life, there are many things that need to be cleaned, and there are many kinds and links that need to be cleaned, such as the removal of oil, dust, surface rust and so on. The common manual cleaning methods are slow and costly. The spray cleaning machine can batch clean the workpiece with uniform effect, strong controllability and low cost. Therefore, the spray cleaning machine is increasingly widely used in all walks of life.
高压喷淋清洗机的特点
Characteristics of high pressure spray cleaning machine
1.速度快,效果统一,内槽和外槽全不锈钢。
High speed, uniform effect, all stainless steel inner and outer grooves.
2.具有清洗液喷洗、清水喷淋漂洗、风机吹水、热风吹干等功能的新颖连续式清洗设备。
2. New continuous cleaning equipment with functions of cleaning solution spraying, rinsing with clean water, fan blowing, hot air drying, etc.
3.仪器工作时间,温度,功率(可调)。
3. Working time, temperature and power of the instrument (adjustable).
4.它对生产效率大大提高,节约成本。
4. It greatly improves the production efficiency and saves the cost.
高压喷淋清洗机的组成要求
Composition requirements of high pressure spray cleaning machine
高压喷淋清洗机可连续长时间工作、内置式安全发热系统、可调式温度控制系统、安全及操作简便、可按客户要求设计及制造 。
High pressure spray cleaning machine can work continuously for a long time, built-in safety heating system, adjustable temperature control system, safe and easy to operate, can be designed and manufactured according to customer requirements.
(1)可大批量连续自动作业。
(1) It can work continuously and automatically in large quantities.
(2)适用于简单结构及管件制品清洗。
(2) It is suitable for cleaning simple structure and pipe fittings.
(3)可采用镀锌及不锈钢外壳,内部配PU喷淋管道,封闭经过式通道。整机为全封闭结构,采用不锈钢或(方通)骨架焊接而成,清洗机上罩部分采用单层结构,采用1.2mm 厚的不锈钢钢板制作,外贴有保温层,降低能耗。
(3) Galvanized and stainless steel shell can be used, with PU spray pipe inside, closed passage. The whole machine is a fully enclosed structure, which is welded by stainless steel or (Fangtong) framework. The upper cover of the cleaning machine adopts a single-layer structure, which is made of 1.2mm thick stainless steel plate, and is pasted with an insulating layer to reduce energy consumption.
高压喷淋清洗机的液箱采用单层结构,采用SUS304不锈钢1.2mm 厚的不锈钢板制作,内部用隔板分成几个区域,分别实现对清洗液的过滤、铁屑的沉淀、滤油、分油,液箱设有补水口、排液口、溢水口。底部为两边向中间倾斜,清洗液从液箱底部的排液口集中排出。
The liquid tank of the high-pressure spray cleaning machine adopts a single-layer structure and is made of SUS304 stainless steel plate with 1.2mm thickness. The inner part is divided into several areas by a partition plate to realize the filtration of the cleaning liquid, the precipitation of iron filings, the oil filtration and the oil separation respectively. The liquid tank is equipped with a make-up port, a discharge port and an overflow port. The bottom is inclined from both sides to the middle, and the cleaning liquid is discharged from the liquid outlet at the bottom of the tank.
