一、准备开机

1、 Ready to power on

1.将滤芯直接放在支架上，根据滤芯的位置，调整限位开关位置，使振动子行程正好满足清洗要求。

1. Put the filter element directly on the support, and adjust the position of the limit switch according to the position of the filter element to make the vibrator stroke just meet the cleaning requirements.

2.调节振动子前后位置，使振动子的辐射面正好在工件中心。调节振动子前后高度使振动子的辐射面与滤芯的高点间隙保持在2~4mm左右，不碰撞、不磨擦为宜。

2. Adjust the front and back position of the vibrator so that the radiation surface of the vibrator is just in the center of the workpiece. Adjust the front and back height of the vibrator to keep the clearance between the radiation surface of the vibrator and the high point of the filter element at about 2 ~ 4mm, and it is appropriate to avoid collision and friction.

3.打开进水阀进水，调节溢水阀，使振头入水约10mm~15mm。调节进水阀使系统进出水平衡。

3. Open the water inlet valve and adjust the overflow valve to make the vibrator enter water about 10 mm ~ 15 mm. Adjust the inlet valve to balance the inlet and outlet water of the system.

4.接通电源，确认电气控制柜内空气开关合上，将面板开关合上，这时面板上定时器指示灯亮。系统准备就绪。

4. Turn on the power supply, make sure that the air switch in the electrical control cabinet is closed, and turn on the panel switch. At this time, the indicator light of the timer on the panel is on. The system is ready.

二、开始清洗

2、 Start cleaning

1.根据清洗工件的要求，设定定时器清洗时间。

1. According to the requirements of workpiece cleaning, set the timer cleaning time.

2.选择按下控制柜移动绿色开关，即为开，振动子沿X轴方向往复移动。

2. Select to press the green switch of the control cabinet, that is on, and the vibrator moves back and forth along the x-axis direction.

3.选择启动“超声”，系统开始频率扫描，即产生超声波，开始清洗。

3. Select "ultrasonic" to start the frequency scanning of the system, that is, to generate ultrasonic and start cleaning.

二、开始清洗

2、 Start cleaning

1.根据清洗工件的要求，设定定时器清洗时间。

1. According to the requirements of workpiece cleaning, set the timer cleaning time.

2.选择按下控制柜移动绿色开关，即为开，振动子沿X轴方向往复移动。

2. Select to press the green switch of the control cabinet, that is on, and the vibrator moves back and forth along the x-axis direction.

3.选择启动“超声”，系统开始频率扫描，即产生超声波，开始清洗。

3. Select "ultrasonic" to start the frequency scanning of the system, that is, to generate ultrasonic and start cleaning.

三、中间停机更换工件

3、 Intermediate stop to replace workpiece

1.清洗设定时间结束时，机械运转和超声波都会停止。

1. At the end of the set cleaning time, the mechanical operation and ultrasonic will stop.

2.将振动子移动到水平位置一侧，关闭控制柜电源开关。

2. Move the vibrator to the side of the horizontal position and turn off the power switch of the control cabinet.

3.更换同样工件（若工件不相同，请按开机要求重新调整）。

3. Replace the same workpiece (if the workpiece is not the same, please adjust it again according to the startup requirements).

4.按下“电源”开关，上述1~3步骤，系统重新开始工作。

4. Press the "power" switch, the above steps 1-3, the system starts to work again.

四、关机

4、 Shut down

1.选择关闭“超声”，即超声波停止工作。

1. Select "ultrasonic" off, that is, the ultrasonic stops working.

2.选择按下控制柜移动“关”，振动子停止沿X轴方向往复移动。

2. Select to press the control cabinet movement "off", and the vibrator stops to move back and forth along the x-axis direction.
