滚杠式喷淋清洗机主要适用于番茄、黄瓜、山药等球茎类产品的清洗，滚杠清洗机采用多级高压水泵喷淋水雾清洗，有效分离被清洗物表面附着物，模拟雨水清洗基本动作并有效避免了人工清洗中的碰、磕、划伤等现象，提高了工作效率，变人工作业为机械化加工。适合于各种类玉米的清洗工作。

The rolling bar spray cleaning machine is mainly suitable for cleaning bulbous products such as tomatoes, cucumbers, yams, etc. The rolling bar cleaning machine adopts a multi-stage high-pressure water pump to spray water mist for cleaning, effectively separating the surface attachments of the cleaned object, simulating the basic action of rainwater cleaning, and effectively avoiding the phenomena of collision, bump, scratch, etc. in manual cleaning, improving work efficiency and transforming manual operation into mechanized processing. Suitable for cleaning various types of corn.

2、设备整机采用SUS304制作。运行平稳，噪音低。整机有输送区、清洗区、沥水区、及循环水处理区等组成。

2. The entire equipment is made of SUS304. Smooth operation with low noise. The whole machine consists of a conveying area, a cleaning area, a drainage area, and a circulating water treatment area.

3、该设备由槽体、接水槽体、喷水系统、输送装置等主要部分组成。物料放置于输送带上，首先利用高压喷淋系统喷出的高压水流，使物料进行粗洗，使物料上带有得毛皮、泥沙等污物脱离后落入下面的水槽区，物料在滚杠输送带的带动下引动到下一工作区域，再经过高压喷淋清洗，彻底去除表面的污物，使物料清洗的更彻底，更完全。工作过程中，进水管和喷淋水管始终供水，并且各级水泵用水实现分级过滤、分级利用、循环供水。有效的节省了生产成本。

3. The equipment consists of a tank body, a water receiving tank body, a water spraying system, a conveying device, and other main components. The material is placed on the conveyor belt. Firstly, the high-pressure water flow sprayed by the high-pressure spray system is used to roughly wash the material, causing the dirt such as fur and mud on the material to detach and fall into the lower water tank area. The material is driven by the roller conveyor belt to move to the next working area, and then undergoes high-pressure spray cleaning to completely remove surface dirt, making the material cleaning more thorough and complete. During the work process, the inlet pipe and sprinkler pipe always provide water, and the water used by each level of water pump is graded for filtration, utilization, and circulating water supply. Effectively saving production costs.

水箱内的污水排出设备，进入污水回收池。结合公转自转原理设计而成的滚杠式输送网带，使滚杠在输送物料过程中，滚杠在导轨的作用下，实现了自传，滚杠的自传带动物料本身也发生连续性转动，加上合理的喷嘴分布设计，使物料在运行过程中，更好的接受全面的喷淋系统的清洗。

The sewage discharge equipment inside the water tank enters the sewage recovery tank. The roller conveyor belt is designed based on the principle of revolution and rotation, which enables the roller to self transmit during the material transportation process under the action of the guide rail. The self transmission belt of the roller also undergoes continuous rotation of the material itself. With a reasonable nozzle distribution design, the material can better receive comprehensive cleaning by the spraying system during operation.
