超声波清洗机广泛应用于铁路、轿车、宇宙、航空、机械、电子、液晶(LCD )制造、光学、医疗、电镀、涂装及真空电镀预处理等职业。 超声波清洗机的功率也是清洗机的超声波输出功率。
Ultrasonic cleaning machine is widely used in railway, car, aerospace, machinery, electronics, liquid crystal (LCD) manufacturing, optics, medical, electroplating, coating and vacuum electroplating pretreatment. The power of the ultrasonic cleaning machine is also the ultrasonic output power of the cleaning machine.
一般来说,超声波功率越大清洗力越强,效率也越高。 购买超声波清洗机的时候,不仅能看到清洗机的容量和频率,还能看到超声波功率的大小。 超声波清洗机的清洗作用不好是因为没有选择合适的功率。 以下,在小篇中说明应该如何选择超声波清洗机的力量。
Generally speaking, the greater the ultrasonic power, the stronger the cleaning force and the higher the efficiency. When buying the ultrasonic cleaning machine, you can not only see the capacity and frequency of the cleaning machine, but also see the size of the ultrasonic power. The cleaning effect of the ultrasonic cleaning machine is not good because it does not choose the appropriate power. Below, explain how to choose the power of ultrasonic cleaning machine in the small chapter.
另一方面,超声波清洗机的功率——如何选择超声波清洗机的频率
On the other hand, the power of ultrasonic cleaning machine - how to choose the frequency of ultrasonic cleaning machine
超声波空化阀值与超声波频率有密切关系。 频率越高,空化阀也越高。 频率越低,空化阀值也越低,现在容易产生气穴效应,另外,在低频的状况下,液体紧缩,受到稀有的作用的时间间隔变长,使气泡成长为更大的尺寸,增强气穴强度,有利于超声波清洗作用。
Ultrasonic cavitation threshold is closely related to ultrasonic frequency. The higher the frequency, the higher the cavitation valve. The lower the frequency is, the lower the cavitation threshold is. Now it is easy to produce cavitation effect. In addition, under the condition of low frequency, the liquid is compressed, and the time interval of rare effect becomes longer, which makes the bubble grow into a larger size and enhances the cavitation intensity, which is conducive to the ultrasonic cleaning effect.
因此,低频超声波清洗机适用于大型部件、污垢与清洗工件外观的粘合度高的状况,例如轿车发动机、阀门等。 但是,低频超声波清洗机容易腐蚀清洗材料的外观,其频率低,产生的噪音也相对较大。 因此,对于工件外观高、硬度差的部件,选择低频率是不合适的。
Therefore, low frequency ultrasonic cleaning machine is suitable for large parts, dirt and cleaning workpiece appearance of high adhesion, such as car engine, valve, etc. However, low frequency ultrasonic cleaning machine is easy to corrode the appearance of cleaning materials, its frequency is low, and the noise is relatively large. Therefore, for parts with high appearance and poor hardness, it is not appropriate to select low frequency.
高频超声波清洗机的透过力强,即使是相同的声音强度,也比低频产生的气穴气泡的数量多,因此适合清洗比较微细、外观构造复杂、盲孔多的零件。
High frequency ultrasonic cleaning machine has strong transmission force, even if it has the same sound intensity, it also produces more cavitation bubbles than low frequency. Therefore, it is suitable for cleaning parts with relatively fine appearance, complex structure and many blind holes.
另外,高频超声波清洗机的噪音也比较小,但空蚀强度低,适合比较微细的零件,清洗污垢和清洗后的工件的外观密合度弱的状况。
In addition, the noise of the high-frequency ultrasonic cleaning machine is also relatively small, but the cavitation intensity is low, which is suitable for the situation that the cleaning dirt and the appearance of the workpiece after cleaning are weak.
