The through type cleaning machine uses a specially designed chain and conveyor belt to transport workpieces, and has functions such as cleaning, rinsing, blowing water, drying, and oiling. As a novel continuous conveying cleaning equipment, the through type cleaning machine manually places the workpiece on the conveyor belt. The workpiece automatically passes through various cleaning rooms for cleaning, and the cleaning solution automatically flows into the return tank. After purification treatment, it can be recycled and equipped with a mist recovery device, which can be used without external pipelines.

通过式清洗机具有多工位，功能全，结构合理，操作方便，清洗效果好的优点，对于流水线零件的清洗，改善劳动环境，提高清洗质量有重要意义。其使用范围广泛，适用于各种五金零件，压铸件，液压件，齿轮，轴承，汽车零部件等各种制造业。

The through type cleaning machine has the advantages of multiple workstations, full functionality, reasonable structure, convenient operation, and good cleaning effect. It is of great significance for the cleaning of assembly line parts, improving the labor environment, and improving cleaning quality. It has a wide range of applications and is suitable for various manufacturing industries such as hardware parts, die-casting parts, hydraulic components, gears, bearings, automotive components, etc.

通过式清洗机工作前先检查清洗液的配方浓度和配方比例是否合适，水箱液面高度是否够；分别调定清洗液箱和漂洗液箱的电接点温度计为50-60度；用钥匙将电源控制开关，置于开位置；开启加热器，使其开始自动加温；开启浮油排除装置开始浮油排除，因此式水泵未开启，水面平静，排油效果好。

Before working, check whether the formula concentration and proportion of the cleaning solution are appropriate, and whether the liquid level in the water tank is high enough; Set the electric contact thermometer of the cleaning solution tank and rinsing solution tank to 50-60 degrees respectively; Use the key to place the power control switch in the on position; Turn on the heater to start automatic heating; Turn on the floating oil removal device to start the floating oil removal, so the water pump is not turned on, the water surface is calm, and the oil removal effect is good.

等温度升到预定值后即开始工作，操作者根据需要选择开关，按每个单动按钮，使水泵，吸雾，输送等全部动作。当机器运行后，操作工人便可以在装料口不断地把零件装载输送网带，清洗，漂洗，吹干，输出，在卸料口取下清洗好的零件。

After the temperature rises to the predetermined value, the operation begins. The operator selects the switch according to needs and presses each single action button to activate the water pump, mist suction, transportation, and other functions. After the machine is running, the operator can continuously load the parts onto the conveyor belt at the loading port, clean, rinse, blow dry, output, and remove the cleaned parts at the unloading port.
