超声波清洗机的机械清洗方法

Mechanical cleaning method of ultrasonic cleaning machine

1.手动清除方法手动方法? 使用金属刷，刮刀和其他工具清除零件表面的污垢。 该方法还包括使用棉，丝绸，合成纤维产品和绒面革擦拭零部件表面以去除污垢。

1. Manual method? Manual method? Use metal brushes, scrapers and other tools to remove dirt from the surface of parts. The method also includes wiping parts with cotton, silk, synthetic fiber products and suede to remove dirt.

2.机械工具的清洁方法使用电动或气动工具驱动金属刷，软砂轮等，以清除零件表面上的积碳，铁锈，油漆等。

2. Cleaning method of mechanical tools: use electric or pneumatic tools to drive metal brush, soft grinding wheel, etc. to remove carbon, rust, paint, etc. on the surface of parts.

3.压缩空气吹扫法使用压缩空气吹扫覆盖零件的干粉尘，油泥等。

3. Compressed air purging method uses compressed air to purge dry dust and oil sludge covering parts.

4.高压水洗方法

4. High pressure water washing method

超声波清洗机的标准保养方法

Standard maintenance method of ultrasonic cleaning machine

1：电源为AC 380v。 (三相四线)

1: The power supply is AC 380V. (three phase four wire)

2：首先将信号线连接在超声波电源和清洁箱之间。 (复选标记连接)

2: First, connect the signal line between the ultrasonic power supply and the cleaning box. (check mark connection)

3：将液体倒入清洗槽中，高度约为300mm。 当储液罐中的液体达到储液罐高度的一半时，其温度可达到40-55度。

3: Pour the liquid into the cleaning tank, about 300 mm high. When the liquid in the tank reaches half of the height of the tank, the temperature can reach 40-55 degrees.

4：将要清洗的工件放入清洗槽，并尽量不要直接接触工件底部。 请勿撞击清洁箱的侧壁。

4: Put the workpiece to be cleaned into the cleaning tank, and try not to directly contact the bottom of the workpiece. Do not hit the side wall of the cleaning box.

5：设置超声的工作时间(注意时间不能为零)，按超声的开始按钮，超声开始工作。

5: Set the working time of ultrasound (note that the time cannot be zero), and press the start button of ultrasound to start working.

6：清洁时间取决于工件的油污程度。

6: The cleaning time depends on the degree of oil contamination on the workpiece.

7：关闭循环过滤器时，请关闭过滤器出口阀。

7: When closing the circulating filter, please close the outlet valve of the filter.

8：定期清洁清洁槽底部的污泥。

8: Clean the sludge at the bottom of the tank regularly.

9：如果在夏天长时间不使用设备(7天)，则应干净地排出清洁槽中的液体;在冬天，须确保清洁槽不会冻结。

9: If the equipment is not used for a long time in summer (7 days), the liquid in the cleaning tank should be drained clean; in winter, the cleaning tank must not be frozen.

10：如果车间灰尘较大，应每月使用压缩空气清洁配电柜中的灰尘。

10: If the workshop is dusty, compressed air should be used to clean the dust in the distribution cabinet every month.

超声波清洗机要长时间正常工作，注意其维护和日常维护工作非常重要。 除了避免不规则操作外，还须定期维护和维护清洁机并进行以下工作：

It is very important to pay attention to the maintenance and daily maintenance of the ultrasonic cleaning machine. In addition to avoiding irregular operation, it is also necessary to regularly maintain and maintain the cleaning machine and carry out the following work:

①定期清理储存箱中被污染的清洁液。

① Clean the contaminated cleaning solution in the storage tank regularly.

②让油泵定期运转一次，每次至少10分钟。

② Let the oil pump run regularly for at least 10 minutes each time.

③洗衣机用完后，盖上盖子以防止灰尘和湿气。

③ Cover the washing machine after use to prevent dust and moisture.
